2022 Harley-Davidson Pan America 1250 Special (G.I. Enthusiast Collection) for Sale

FB BLU/WHT SNDUsed Motorcycles
Available at: Stubbs Harley-Davidson in Houston, TX
Availability: In Stock

Price

$12,884

Get Price Alerts!
2022 Harley-Davidson Pan America 1250 Special (G.I. Enthusiast Collection) in Houston, Texas
Previous
Next
2022 Harley-Davidson Pan America 1250 Special (G.I. Enthusiast Collection) in Houston, Texas
Previous
Next

Request More Information

By pressing SUBMIT, you agree that DX1, LLC and Stubbs Harley-Davidson in Houston, TX may call/text you at the number provided, for either informational or marketing purposes, using an automatic telephone dialing system or pre-recorded/artificial voices. Msg/data rates may apply. You don’t need to consent as a condition of any purchase & you may revoke your consent at any time. You also agree to our Privacy Statement & Terms of Use.
The 2022 G.I. Enthusiast Collection - A Salute to New Adventures

A modern interpretation of the military-issued look of decades past, the Pan America™ 1250S G.I. honors Harley-Davidson’s community of riders who have and continue to serve in the US Armed Forces. Draped in stunning Mineral Green Denim Deluxe paint with military inspired graphics, this limited-edition model is for those fueled by exploration who dream of crossing continents and forging lasting memories.

Pan America™ 1250S G.I. Features

  • Exclusively for the Pan America™ 1250 Special model
  • Mineral Green Denim Deluxe paint
  • Enthusiast Collection logo on front fairing
  • Distinctive, military-inspired graphics
  • All technical features are identical to the Pan America™ 1250 Special model
Request More Information Print Brochure
Calculate Payment
Schedule a Test Ride

2022 Harley-Davidson Pan America 1250 Special (G.I. Enthusiast Collection)

Condition
Used
Stock Number
305102
Category
Motorcycles
Model Type
Enthusiast
Model Code
RA1250S
VIN
1HD1ZES19NB305102
Miles
3,221
Color
FB BLU/WHT SND

Adaptive Lighting

  • ADVANCED DAYMAKER ADAPTIVE HEADLAMP: Utilizing the ABS IMU to determine the lean angle of the motorcycle, this system automatically projects additional light into corners to illuminate areas of the road that may be unlit by an LED headlamp without this tech. Includes three LED elements per side, located just above the main Daymaker headlamp. The adaptive lamps illuminated in sequence based on motorcycle lean angle: at 8, 15, and 23 degrees. Rather than just switching on and off, the current to the adaptive elements ramps up gradually so the additional lighting is progressive and appears seamless.

Great Expectations

  • PAN AMERICA 1250 MODELS ARE EQUIPPED: With the latest technology you'd expect for the category - six-axis IMU, customizable ride modes, Bluetooth connectivity and moving map navigation features in a 6.8 in (173 mm) touchscreen display.

Off-Road Ready

  • ALUMINUM SKID PLATE: Protects the engine crankcase from impacts.
  • BRUSH GUARDS: Protect the radiator and help support the motorcycle in a tip-over.
  • STEERING DAMPER: To enhance dynamic performance during aggressive off-road riding.
  • NO-TOOL-NEEDED ADJUSTABLE BRAKE PEDAL: Which can switch between two positions to improve control and comfort when the rider is standing.
  • SEMI-ACTIVE FRONT AND REAR SUSPENSION: With a specific Off-Road mode programmed to help the rider maintain traction and control over rougher roads and terrain.

Pricing

  • California customers are subject to a California Emissions fee; see Dealer for details - $200
  • Spoked Wheel option - $624
  • Adaptive Ride Height option - $1,200

Suspension - Rider Comfort

  • VEHICLE LOADING CONTROL: This system senses the weight of the rider, passenger and luggage to select optimum suspension sag by automatically adjusting rear preload.
  • SEMI-ACTIVE SUSPENSION SYSTEM: This system reacts to suspension position, vehicle speed, vertical acceleration, roll angle and rate, throttle, brake inputs and the selected Ride Mode to maintain the desired comfort setting. There are five pre-programmed profiles, which are baked into each Ride Mode: 1)Comfort - More suspension compliance and isolating the rider from rough road conditions. 2)Balanced - A balance of ride comfort and ride control, for all-around riding. 3)Sport - Maximum ride control with higher damping rates - what we call "spirited riding". 4)Off-Road Soft - Reduced initial damping to increase suspension compliance to better absorb larger obstacles and to reduce kickback: ideal for logging roads, washboards and rocky terrain. 5)Off-Road Firm - Increased initial damping for aggressive riding or when less body float is desired: ideal for soft / loamy terrain.

General Information

Manufacturer
Harley-Davidson
Model Year
2022
Model
Pan America 1250 Special (G.I. Enthusiast Collection)
Model Code
RA1250S
Stock Number
305102
Color
FB BLU/WHT SND

Brakes/Wheels/Tires

Brakes

Front - Radially mounted, monoblock, 4-piston caliper

Rear - Floating, single piston caliper

Rider Safety Enhancements - Anti-Lock Brake System (ABS), Electronic Linked Braking (ELB), Traction Control System (TCS), Hill Hold Control, Cornering Enhanced Anti-Lock Brake System (C-ABS), Cornering Enhanced Electronic Linked Braking (C-ELB), Cornering Enhanced Traction Control System (C-TCS)

Wheels

Optional Style Type - Anodized aluminum tubeless laced

Wheel Colors
Satin Black
Tires

Front - 120/70R19 60V

Rear - 170/60R17 72V

Type - Michelin® Scorcher® “Adventure”, Radial

Dimensions

Length
89.4 in. (2,270 mm)
Weight

As shipped - 534 lb. (242 kg)

In running order - 569 lb. (258 kg)

Ground Clearance

6.9 in.

Right / Left Lean Angle - 42°

Wheelbase
62.4 in. (1,585 mm)
Seat Height
Laden (High seat position) - 32 in. (814 mm)7

Drivetrain

Primary Drive
Gear, 49 / 89 ratio

Electrical

Instrumentation
Gauges - 6.8 in. viewable area TFT display with speedometer, gear, odometer, fuel level, clock, trip, ambient temp, low temp alert, side stand down alert, TIP over alert, cruise, range and tachometer indication BT capable - phone pairing to access phone calls, music, navigation (H-D App ONLY)
Lighting
Lights (as per country regulation), headlamp, tail / stop / front signal8 - Daymaker Adaptive LED Headlamp with 6-segment LED banking lamp, LED Tail / Stop lamp with signature tail lighting, LED Bullet Turn Signals
Advanced Electronics

Color TFT with Touch

Headset Specifications (if equipped) - Bluetooth

Hands-free Mobile Phone - via Bluetooth

Voice Recognition Languages: Phone functions only/Tuner/Media/Navigation - Phone dependent

Text-to-Speech (TTS) Languages - Phone dependent

Rider/Passenger Intercom - Headset function only

Vehicle Information Screen (Air temperature, oil pressure and EITMS) - TPMS, Engine temp, Battery Voltage, Ambient Air Temp

USB - Charging and Instrument update, USB-C, 5V, 3A

Bluetooth - Phone/Media Supported

Rider Safety Enhancements - Wheel Lift Mitigation, Enhanced Lift Mitigation

Engine

Engine
Revolution® Max 12501
Horsepower
150 hp / 112 kW @ 9,000 rpm
Displacement
1,252 cc (76.4 ci)
Bore x Stroke
4.13 x 2.85 in. (105 x 72.3 mm)
Torque

94 ft-lb (127 Nm)2 @ 6,750

Testing method - J1349

Rider Safety Enhancements - Drag-Torque Slip Control System (DSCS), Cornering Drag-Torque Slip Control System (C-DSCS)

Compression Ratio
13.0:1
Gear Ratio

Overall

1st - 13.11

2nd - 9.687

3rd - 7.509

4th - 6.057

5th - 5.08

6th - 4.436

Fuel System
Electronic Sequential Port Fuel Injection (ESPFI)3
Exhaust
2-into-1-into-1; catalyst in header
Fuel Capacity
5.6 gal. (21.2 l)
Oil Capacity
4.75 qt. (4.5 l)
MPG Rating
Estimated City / Hwy - 46 mpg (5.1 l/100 km)5

Operational

Front Suspension
47 mm inverted fork with electronically adjustable semi-active damping control. Aluminum fork triple clamps.
Rear Suspension
Shocks - Linkage-mounted monoshock with automatic electronic preload control and semi-active compression and rebound damping
Rake
25°
Trail
4.3 in. (108 mm)

Other

Includes
Security System and Cruise Control
